Round Flat Burner Pan Kit - 30VDC

18" Round Flat Burner Pan with Opening for Pilot Burner

• 6" Diameter Spiral - 43K BTU's (316 Stainless Steel)
• 1/2 Gas Inlet with NG Orifice or LP Air Mixer
• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner
• Natural Gas or Liquid Propane
• Liquid Propane; Includes 120V Safety Backup Valve
• Includes 30VDC Power Supply
•  (1) 18" Whisper Free Flex Gas Line 1/2"
• Note: Holds 29lbs of Fire Glass / 2 Bags of Lava Rock / 1 Bag of Rolled Lava Stone

24" Round Flat Burner Pan with Opening for Pilot Burner

• 12" Diameter Spiral Burner - 85K BTU's (316 Stainless Steel)
• 1/2 Gas Inlet with NG Orifice or LP Air Mixer
• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner
• Natural Gas or Liquid Propane
• Liquid Propane; Includes 120V Safety Backup Valve
• Includes 30VDC Power Supply
• (1) 18" Whisper Free Flex Gas Line 1/2"

• Note: Holds 52lbs of Fire Glass / 3 Bags of Lava Rock / 1 Bag of Rolled Lava Stone

30" Round Flat Burner Pan with Opening for Pilot Burner

• 18" Diameter Spiral Burner - 162K BTU's (316 Stainless Steel)
• 1/2 Gas Inlet with NG Orifice or LP Air Mixer
• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner
• Natural Gas or Liquid Propane
• Liquid Propane; Includes 120V Safety Backup Valve
• Includes 30VDC Power Supply
• (1) 18" Whisper Free Flex Gas Line 1/2"

• Note: Holds 81lbs of Fire Glass / 5 Bags of Lava Rock / 2 Bag of Rolled Lava Stone

36" Round Flat Burner Pan with Opening for Pilot Burner

• 24" Diameter Spiral Burner - 170K BTU's (316 Stainless Steel)
• 1/2 Gas Inlet with NG Orifice or LP Air Mixer
• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner
• Natural Gas or Liquid Propane
• Liquid Propane; Includes 120V Safety Backup Valve
• Includes 30VDC Power Supply
• (1) 24" Flex Line 3/4" with 1/2" x 3/4" Reducer
• Note: Holds 117lbs of Fire Glass / 6 Bags of Lava Rock / 2 Bags of Rolled Lava Stone

48" Round Flat Burner Pan with Opening for Pilot Burner

• 36" Diameter Spiral Burner - 238K BTU's (316 Stainless Steel)
• 3/4 Gas Inlet with NG Orifice or LP Air Mixer
• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner
• Natural Gas or Liquid Propane
• Liquid Propane; Includes 120V Safety Backup Valve

• Includes 30VDC Power Supply
• (1) 36" Flex Line 3/4"
• Note: Holds 208lbs of Fire Glass / 11 Bags of Lava Rock / 4 Bags of Rolled Lava Stone

Documents

Preinstallation Checklist

Spec Sheet for Low Profile Standard Capacity

Spec Sheet for High Profile Standard Capacity

Spec Sheet for Low Profile High Capacity

Spec Sheet for High Profile High Capacity

Pilot Burner Assembly Differences

AWEIS Troubleshooting Guide

AWEIS Installation Instructions

Automated Fire 101

Flat Pan And Burner Instructions

Drop In Pan And Burner Instructions

Flat Burner Pan Support Structure

Burner Pan Joiner Plate Instructions
