MRCOOL® Universal Series Heat Kit for Air Handler with Circuit Breaker

 Universal air handler heat strip with circuit breaker provides emergency heat to your MRCOOL system. Also providing 15K up to 70K BTU of heating capacity  to keep you comfortable through the winter months.



Compatible Models
MDUI18024036: 5KW - 8W - 10KW
MDUI18036: 10KW
MDUI18048060: 15KW and 20KW

Dimensions:
Depth: 22"
Height: 7"
Width: 12"

Heater Sizes	MAX Fuse Breaker	MIN Circuit Ampacity	BTU	Voltage
5KW	30A	25A	15K - 20K	208/230V
8KW	45A	40A	25K - 30K	208/230V
10KW	60A	50A	30K - 35K	208/230V
15KW	60A/30A	50/25A	50K - 55K	208/230V
20KW	60A/60A	50A	65K - 70K	208/230V



Made in USA

Documents

Manufacture Installation Manual
